Dell B3460dn User Manual

3 Insert the tray.
4 From the printer control panel, select Next > > Clear the jam, press OK > to clear the message and continue
printing.
[x]‑page jam, clear manual feeder. [25y.xx]
1 From the multipurpose feeder, firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
2 Flex the sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten
the edges on a level surface.
Clearing jams 113

Dell B3460dn Specifications

General

Print Technology	Monochrome Laser
Monthly Duty Cycle	Up to 150, 000 pages
Standard Connectivity	USB 2.0, Gigabit Ethernet
Duplex Printing	Yes
Processor Speed	800 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	550 sheets
Memory	256 MB
Maximum Paper Size	Legal (8.5 x 14 inches)
Print Speed	Up to 50 ppm (letter)
