Dell B5460dn Mono Laser Printer - Page 16

1
2
3
1 Internal Solutions Port or printer hard disk connector
2 Option card connector
3 Memory card connector
5 Align the screws with the holes on the controller board shield, and then reattach the controller board shield.
1
2
Additional printer setup 16
