8. Lift the hard drive in an upward direction to remove it from the hard-drive bracket.
Installing the Hard Drive
1. If a 3.5–inch hard drive is installed on the computer, place the hard drive and press in on the latches of the hard-drive caddy.
2. If a 2.5–inch hard drive is installed on the computer, place the hard drive on the hard-drive caddy and tighten the screws to secure the
hard drive.
3. Secure the hard-drive in the hard-drive cage and slide it inside the compartment.
4. Connect the hard-drive power supply cable and data cable.
5. Install the computer cover.
6. Follow the procedures in After Working Inside Your Computer.
Removing the Speaker
1. Follow the procedures inBefore Working Inside Your Computer.
2. Remove the computer cover.
3. Perform the following steps as shown in the illustration:
a) Disconnect the speaker cable from the system board [1].
b) Press down the clasp, lift and remove the speaker [2,3].
Removing and installing components
17
