Installing the power button
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the power button and provides a visual representation of the installation
procedure.
Steps
1. Thread the power-button cable through the slot on the power-button bracket.
Removing and installing components
19
