100 Removing and Installing Parts
CD/DVD Drive
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the
Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before
removing the cover.
Removing a CD/DVD Drive
1
Follow the procedures in "Before You Begin" on page 61.
2
Remove the drive panel (see "Removing the Drive Panel" on page 81).
3
Disconnect the power cable and the CD/DVD drive data cable from the back of the drive and the
system board.
1 power cable 2 data cable
1
2
