Dell E2225H - Back View

About your monitor 11
Back view
6
With monitor stand
5
Without monitor stand
2
1
3 4
Figure 2. Back view of the monitor
Table 5. Components and descriptions.
Label Description Use
1 VESA mounting holes (100 mm x 100 mm -
behind attached VESA cover)
Wall-mount the monitor using VESA-compatible wall mount kit (100 mm x 100
mm).
2 Security-lock slot
(based on Kensington Security Slot
TM
)
Secure your monitor using a security lock (purchased separately) to prevent
unauthorized movement of your monitor. For more information, see Securing
your monitor using Kensington lock (optional).
3 Barcode, serial number, and service tag
label
See this label if you need to contact Dell for technical support. The Service
Tag is a enables Dell service technicians to identify the specifications of your
monitor and access warranty information.
4 Regulatory label List the regulatory approvals.
5 Cable-management clip To organize the cables.
6 Stand release button Release stand from the monitor.
