Dell E2225H - Monitor Specifications

About your monitor 13
Monitor specifications
Table 7. Monitor specifications.
Model E2225H E2425H
Screen type Active matrix-TFT LCD Active matrix-TFT LCD
Panel technology Vertical Alignment Technology Vertical Alignment Technology
Viewable image dimensions
Diagonal 544.85 mm (21.45 in.) 604.70 mm (23.81 in.)
Active area
Horizontal 478.66 mm ( 18.84 in.) 527.04 mm (20.75 in.)
Vertical 260.28 mm ( 10.25 in.) 296.46 mm (11.67 in.)
Area 124584.58 mm
2
(193.11 in.
2
) 156246.28 mm
2
(242.18 in.
2
)
Pixel pitch 0.2493 mm x 0.2410 mm 0.2745 mm x 0.2745 mm
Pixel per inch (PPI) 103 93
Viewing angle
Horizontal 178° (typical) 178° (typical)
Vertical 178° (typical) 178° (typical)
Brightness 250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio 3000:1 (typical) 3000:1 (typical)
Faceplate coating Anti-Glare with 3H hardness Anti-Glare with 3H hardness
Backlight LED Edgelight System LED Edgelight System
Response time (Gray to Gray) 8 milliseconds (Normal mode)
5 milliseconds (Fast mode)
8 milliseconds (Normal mode)
5 milliseconds (Fast mode)
Color depth 16.7 million colors 16.7 million colors
Color gamut NTSC mininum 72% (CIE 1931)
NTSC mininum 83% (CIE 1976)
NTSC mininum 72% (CIE 1931)
NTSC mininum 83% (CIE 1976)
Dell display manager compatibility Yes Yes
Connectivity • 1 x DisplayPort 1.2 (HDCP 1.4) (supports
up to FHD 1920 x 1080 75 Hz)
• 1 x VGA
• 1 x DisplayPort 1.2 (HDCP 1.4) (supports
up to FHD 1920 x 1080 75 Hz)
• 1 x VGA
Bezel width (edge of the monitor to active
area)
12.80 mm (Top)
12.80 mm (Left/Right)
16.92 mm (Bottom)
12.80 mm (Top)
12.80 mm (Left/Right)
16.92 mm (Bottom)
Security Security-lock slot (cable lock sold
separately)
Security-lock slot (cable lock sold
separately)
Tilt angle -5° to 21° -5° to 21°
