30 Setting up the monitor
VESA wall mounting (optional)
Figure 22. VESA wall mounting
NOTE: Use M4 x 10 mm screws to connect the monitor to the wall-mounting kit.
Refer to the instructions that come with the VESA-compatible base mounting kit.
1. Place the monitor panel on a soft cloth or cushion on a stable flat table.
2. Remove the stand. For more information, see Removing the monitor stand.
3. Use a screwdriver to remove the four screws securing the plastic cover.
4. Attach the mounting bracket from the wall mounting kit to the monitor.
5. Mount the monitor on the wall. For more information, see the documentation that is shipped with the wall mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall-mount bracket with minimum weight/load bearing capacity of 9.36 kg (20.63 lb)
for E2225H, 12.64 kg (27.86 lb) for E2425H.
Using tilt
You can tilt the monitor for the most comfortable viewing angle.
NOTE: The stand is not attached when the monitor is shipped from the factory.
Figure 23. Tilt adjustment
