7
Jumpers and connectors
System board jumpers and connectors
Figure 37. System board jumpers and connectors
Table 10. System board jumpers and connectors
Ite
m
Connector Description
1 FP_USB Front panel USB connector
2 CTRL_PNL Control panel
110
