Figure 35. Removing and installing the screws on the system board
1. screw (8)
Next steps
1. Install the system board.
Related Tasks
Removing memory modules
Removing an expansion card
Removing the heat sink
Removing the processor
Removing the optional iDRAC port card
Installing the system board
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
90
