Installing and Configuring the Switch 21
Sample Setup Wizard Session
This section describes an Easy Setup Wizard session. The following values are
used in the example session:
•SNMP is enabled.
• The default user name "root" and password "calvin" are used. The Wizard
does not display the password as it is entered.
• The OOB management interface uses IP address 192.168.2.1.
• The default gateway uses IP address 192.168.2.0.
• The default VLAN management interface uses IP address 2.2.2.80.
NOTE: In the example below, the previously entered value or the default value is
enclosed within brackets [ ]. If you press <Enter> with no value selected, the value
displayed in the brackets is used. Help text is in parentheses.
The following example contains the sequence of prompts and responses
associated with running a sample Dell Easy Setup Wizard session, using the
input values listed above.
After the switch initializes and boots up, the following text is displayed:
Welcome to Dell Easy Setup Wizard
The setup wizard guides you through the initial switch
configuration, and gets you up and running as quickly
as possible. You can skip the setup wizard, and enter
CLI mode to manually configure the switch. You must
respond to the next question to run the setup wizard
within 60 seconds, otherwise the system will continue
with normal operation using the default system
configuration. Note: You can exit the setup wizard at
any point by entering [Ctrl+c].
Would you like to run the setup wizard (you must
answer this question within 60 seconds)? [Y/N] y
The system is not set up for SNMP management by
default. To manage the switch using SNMP (required for
Dell Network Manager) you can
