Page #60 background image
Identifier GUID-BF7F1ECA-BC62-4949-B1BE-EC64E351719E
Status Released
Removing the speakers
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-E7C727AF-B7E4-4DED-9219-77CA221B429C
Status Released
Prerequisites
1 Remove the base cover.
2 Remove the solid-state drive/Intel Optane.
Identifier GUID-7BF4E484-4E57-4C0F-BA88-F794503F9E8A
Status Released
Procedure
1 Disconnect the speaker cable from the system board.
2 Note the speaker cable routing and remove it from the routing guides on palm rest and keyboard assembly.
3 Lift the speakers, along with the cable, o the palm rest and keyboard assembly.
26
60 Removing the speakers
