Dell Inspiron 3480 User Manual

Identifier GUID-A99140DB-7AF3-4218-B305-532FF94DF51D
Status Released
Replacing the power-adapter port
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-D624BB3E-2596-4949-B5C9-75E580DF8189
Status Released
Procedure
1 Place the power-adapter port into the slot on the palm rest and keyboard assembly.
2 Adhere the power-adapter port cable to the palm-rest and keyboard assembly.
3 Replace the screw (M2x2) that secures the power-adapter port to the palm rest and keyboard assembly.
39
92 Replacing the power-adapter port

Dell Inspiron 3480 Specifications

General

Graphics	Intel UHD Graphics 620
Processor	Intel Core i5-8265U
Display	14-inch HD (1366 x 768)
RAM	4GB DDR4
Storage	1TB HDD
Operating System	Windows 10 Home
Battery	3-cell 42 WHr
Ports	2 x USB 3.1 Gen 1, 1 x USB 2.0, 1 x HDMI, 1 x SD card reader
Wireless	802.11ac
