Dell J1FD8 - Installing the Solid State Drive Bracket

Installing the solid state drive bracket
Steps
1. Align the bracket and insert it into the slot on the palmrest [1].
2. Replace the single (M2x3) screw to secure the bracket to the palmrest [2].
