Next steps
1. Replace the keyboard.
2. Replace the coin cell battery.
3. Replace the system board.
NOTE: System board can be replaced with heatsink assembly attached.
4. Replace the WLAN card.
5. Replace the DC-in.
6. Replace the memory module.
7. Replace the speaker.
8. Replace the battery.
9. Replace the base cover.
10. Replace the microSD card.
11. Follow the procedure in after working inside your computer.
Display assembly
Removing the display assembly
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the microSD card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the WLAN card.
90
Disassembly and reassembly
