Installing M.2 Solid State Drive
1 Align the notch on the SSD card with the tab on the SSD card connector and slide the card into the slot.
2 Align the screw hole on the SSD card with the screw hole on the system board.
3 Replace the screw that secures the SSD card to the system board.
4 Install the:
a battery
b base cover
5 Follow the procedure in After working inside your computer.
Power switch board
Removing power switch board
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the power switch:
18
Disassembly and reassembly

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell Latitude 3190 2-in-1 and is the answer not in the manual?

Dell Latitude 3190 2-in-1 Specifications

General IconGeneral
GraphicsIntel UHD Graphics 600
ProcessorIntel Celeron N4100
RAM4GB DDR4
Storage64GB eMMC
Display11.6-inch HD (1366 x 768) Touchscreen
Operating SystemWindows 10 Pro
Battery3-Cell 42 WHr Battery
Weight1.44 kg (3.17 lbs)
Ports1 x HDMI
Wireless802.11ac Wi-Fi, Bluetooth 5.0
Camera720p HD camera
