Dell Latitude 7430 Service Manual

5. Peel back the tape that secures the speaker cable to the palm-rest and touchpad.
6. Unroute and remove the speaker cable from the routing guides along the bottom side of the thermal fan and on the
palm-rest and keyboard assembly.
7. Using a plastic scribe, pry the speakers along with the cable off the palm-rest and keyboard assembly.
Installing the speakers
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE:
If the rubber grommets are pushed out when removing the speakers, push them back in before replacing the
speakers.
The following image indicates the location of the speakers and provides a visual representation of the installation procedure.
64
Removing and installing components

Dell Latitude 7430 Specifications

General

Processor	12th Gen Intel Core i5/i7
RAM	Up to 32GB DDR4
Graphics	Intel Iris Xe Graphics
Bluetooth	Bluetooth 5.2
Display	14-inch FHD (1920 x 1080)
Storage	Up to 1TB SSD
Operating System	Windows 11 Pro
Battery	4-cell 58 Whr
Ports	HDMI 2.0
Wireless	Wi-Fi 6E (802.11ax)
Security	Fingerprint reader, Smart Card reader, TPM 2.0
