Dell Latitude 7480 - Page 41

4. To disconnect the eDP cable:
a. Un route the WLAN and WWAN cables from the routing channels [1].
b. Disconnect the IR cable from the system board [2].
c. Remove the M2.0 x 3.0 screw that secures the eDP cable [3].
d. Remove the eDP cable bracket [4].
e. Disconnect the eDP cable from the system board [5].
f. Un route the eDP cable from the routing clip [6].
Disassembly and reassembly
41
