Dell Latitude 9430 2-in-1 User Manual

Steps
1. Loosen the eight captive screws that secure the base cover to the system.
2. Using a plastic scribe, pry open the base cover starting from the recesses that are located in the U-shaped indents near the
hinges at the top edge of the base cover.
NOTE:
Do not lift the base cover from the top side immediately after prying it from the recesses, as this will cause
damage to the base cover.
3. Work your way around the sides of the base cover.
4. Hold the left and right sides of the base cover, and remove the base cover from the system.
NOTE: If the thermal pad on the back of the base cover gets detached, adhere it back onto the cover.
Installing the base cover
Prerequisites
If you are replacing a component, remove the necessary component before the installation procedure.
About this task
The following image provides a visual representation of the base cover installation procedure.
Removing and installing components
19

Dell Latitude 9430 2-in-1 Specifications

General

Processor	12th Gen Intel Core i5/i7
RAM	Up to 32GB LPDDR5
Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Pro
Display	14 inch, FHD+ (1920 x 1200), Touchscreen
Storage	Up to 1TB PCIe NVMe SSD
Battery	60 Wh
Weight	Starting at 3.2 lbs
Ports	2 x Thunderbolt 4, 1 x HDMI 2.0
Wireless	Wi-Fi 6E, Bluetooth 5.2
Camera	FHD IR Camera
Audio	Stereo speakers
Security	Fingerprint Reader, IR Camera for Windows Hello
