Installing the System Board
1. Align the system board in its place on the computer.
2. Tighten the screws to secure the system board.
3. Connect the following cables to the system board:
a) speaker
b) I/O cable
4. Install:
a) display assembly
b) display-hinge cover
c) speaker
d) palmrest
e) keyboard
f) keyboard trim
g) hard drive
h) base cover
i) battery
j) SD card
5. Follow the procedures in
After Working Inside Your Computer
.
37
