Dell Latitude E7440 - Removing the Display Bezel; Installing the Display Bezel; Removing the Display Panel

Removing the Display Bezel
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery.
3. Pry the edges of the display bezel. Remove the display bezel from the display assembly.
Installing the Display Bezel
1. Align the display bezel in place and snap it in place.
2. Align the hinge covers on display assembly and snap it in place.
3. Install the battery
4. Follow the procedures in After Working Inside Your Computer .
Removing the Display Panel
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) display bezel
3. Remove the screws that secure the display panel to the display assembly. Lift the display panel over.
4. Perform the following steps as shown in the illustration:
a) Peel the LVDS cable connector tape [1].
