Dell OptiPlex 3050 Small Form Factor - Expansion card

Installing the cover
1. Place the cover on the computer and slide the cover until it clicks into place.
2. Tighten the captive screws to secure the cover to the computer.
3. Follow the procedure in After working inside your computer
Expansion card
Removing expansion card
1. Follow the procedure in Before working inside your computer.
2. Remove the cover.
3. Pull the metal tab to open the expansion card latch.
10
Removing and installing components
