Installing the coin cell battery
1. Hold the coin cell battery with the "+" sign facing up and slide it under the securing tabs at the positive side of the
connector.
2. Press the battery into the connector until it locks into place.
3. Install the:
a. cover
4. Follow the procedure in After working inside your computer.
Front Bezel
Removing bezel
1. Follow the procedure in Before working inside your computer.
2. Remove the cover.
3. To remove the front bezel:
a. Lift the tabs to release the front bezel from the computer [1].
b. Remove the front bezel from the computer [2].
Removing and installing components
13
