Installing the bezel
1. Insert the tabs on the bezel into the slots on the computer.
2. Press the bezel until the tabs clicks into place.
3. Install the cover.
4. Follow the procedure in After working inside your computer
Speaker
Removing speaker
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. cover
b. bezel
c. hard drive and optical drive module
3. To remove the speaker:
a. Disconnect the speaker cable from the system board [1].
b. Press the release tabs and pull the speaker out from the computer [2] [3].
14
Removing and installing components
