Dell Optiplex 7070 Small Form Factor User Manual

3 Install the:
a Expansion cards
b Side cover
4 Follow the procedure in After working inside your computer.
Hard drive assembly
Depending on the conguration you choose, you will have either one 3.5–inch hard drive assembly or two 2.5–inch hard drive assembly.
Removing the hard drive assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the Side cover.
3 To remove the hard drive:
a Disconnect the hard drive data cable and power cable from the connectors on the hard drive [1, 2].
b Push the release tab and lift the hard drive assembly from the system [3].
22
Removing and installing components
