Dell Optiplex 7070 Small Form Factor User Manual

Installing the power supply unit or PSU
1 Insert the PSU in the chassis and slide it towards the back of the system to secure it [1, 2].
2 Route the system power cable through the retention clips [3].
3 Connect the power cable to the connector on the system board [4].
4 Replace the screws to secure the PSU to the rear chassis of the system [5].
Removing and installing components
57
