Dell Optiplex 7070 Small Form Factor User Manual

7 Install the:
a Heatsink assembly
b Hard drive and optical drive module
c HDD assembly
d Front bezel
e Side cover
8 Follow the procedure in After working inside your computer.
Speaker
Removing speaker
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
c HDD assembly
d Hard drive and optical drive module
3 To remove the speaker:
a Disconnect the speaker cable from the connector on the system board [1].
b Press the release tab [2] and pull the speaker out from the system [3].
