Dell Optiplex 7070 Small Form Factor User Manual

4 Install the Side cover.
5 Follow the procedure in After working inside your computer.
Hard drive
Removing the hard drive
NOTE
: For congurations shipped with 3.5-inch HDD, follow the same procedure to remove the HDD from its bracket.
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b hard drive assembly
3 Flex the hard drive bracket [1], lift the hard drive [2], and then slide out from the hard drive bracket [3].
NOTE
: Follow the same procedure to remove another 2.5-inch hard drive on the other side of the bracket.
24 Removing and installing components
