Dell Optiplex 7070 Small Form Factor User Manual

4 Install the:
a Heatsink assembly
b Hard drive and optical drive module
c HDD assembly
d Front bezel
e Side cover
5 Follow the procedure in After working inside your computer.
Power supply unit
Removing power supply unit or PSU
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
c HDD assembly
d Hard drive and optical drive module
Removing and installing components
55
