Dell Optiplex 7070 Small Form Factor User Manual

NOTE: Loosen the screws in a sequential order (1,2,3,4) as mentioned on the system board.
Installing heatsink assembly
1 Align the heatsink assembly onto the processor [1].
2 Tighten the 4 captive screws to secure the heatsink assembly to the system board [2].
NOTE
: Tighten the screws in a sequential order (1,2,3,4) as mentioned on the system board.
3 Connect the heatsink assembly fan cable to the connector on the system board [3].
46
Removing and installing components
