Dell OptiPlex 9010 Small Form Factor - Removing and Installing the WLAN Card

Installing the Front Bezel
1. Insert the hooks along the bottom edge of the front bezel into the slots on the chassis front.
2. Push the bezel toward the computer to engage the front bezel retention clips until they click into place.
3. Install the cover.
4. Follow the procedures in After Working Inside Your Computer .
Removing The Wireless Local Area Network (WLAN) Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the screws the secure the antenna puck to the connector. Pull out the antenna puck from the computer.
4. Press the blue tab and lift the latch outwards. Lift and remove the WLAN card from the computer.
