Next steps
1 Replace the base cover
2 Replace the SD memory card
3 Follow the procedure in after working inside your computer
Hard drive
Removing the hard drive assembly
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
Steps
1 Disconnect the hard drive cable from the system board [1].
2 Peel the tape that secures the hard drive cable to the system board [2].
Removing and installing components
23
