Dell P111G - IO Board

Next steps
1 Replace the battery
2 Replace the base cover
3 Replace the SD memory card
4 Follow the procedure in after working inside your computer
IO board
Removing the IO board
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
5 Remove the hard drive assembly
Steps
1 Open the latch and disconnect the I/O board cable from the system board [1].
2 Peel the I/O-board cable from the palm rest and keyboard assembly [2].
Removing and installing components
27
