Dell P111G - WLAN Card

Next steps
1 Replace the battery
2 Replace the base cover
3 Replace the SD memory card
4 Follow the procedure in after working inside your computer
WLAN card
Removing the WLAN card
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
Steps
1 Remove the single (M2x3) screw that secures the WLAN card bracket to the system board [1].
2 Slide and remove the WLAN card bracket that secures the WLAN cables [2].
3 Disconnect the WLAN cables from the connectors on the WLAN card [3].
4 Lift the WLAN card away from the connector [4].
Removing and installing components
39
