Installing the Solid-state drive bracket
Steps
1 Align and replace the solid-state drive bracket on the palmrest and keyboard assembly [1].
2 Replace the single (M2x3) screw that secures the solid-state drive bracket to the palmrest and keyboard assembly [2].
