Installing the M.2 2230 Solid-state drive
Steps
1 Insert the solid-state drive into the solid-state drive slot on the system board [1].
2 Replace the single (M2x3) screw that secures the solid-state drive to the solid-state drive bracket [2].
Removing and installing components
49
