Dell P111G - Page 66

Installing the VGA daughterboard
Steps
1 Place the VGA daughterboard and align the screw holes on the VGA daughterboard with the screw holes on the palmrest and
keyboard assembly [1].
2 Replace the two (M2x3) screws that secure the VGA daughterboard on the palmrest and keyboard assembly [2].
Removing and installing components
65
