Steps
1. Align the rib inside the left hinge cap to the outer sides.
2. Push the left hinge cap down until it clicks in place.
3. Align the rib inside the right hinge cap to the outer sides.
4. Push the right hinge cap down until it clicks in place.
Next steps
1. Install the display assembly.
2. Install the wireless card.
3. Install the base cover.
4. Install the SD card.
5. Follow the procedure in After working inside your computer.
Display bezel
Removing the display bezel
Prerequisites
NOTE: This procedure is applicable for systems with plastic chassis.
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the wireless card.
5. Remove the display assembly.
6. Remove the hinge caps.
About this task
The following images indicate the location of the display bezel and provide a visual representation of the removal procedure.
Removing and installing components
71
