Installing the camera module
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the camera module and provide a visual representation of the installation
procedure.
Steps
1. Adhere the camera module in its slot on the display assembly.
2. Connect the camera cable to the camera module.
Next steps
1. Install the display panel.
2. Install the hinges.
3. Install the display bezel.
4. Install the hinge caps.
5. Install the display assembly.
6. Install the wireless card.
7. Install the base cover.
8. Install the SD card.
9. Follow the procedure in After working inside your computer.
Removing and installing components
85
