eDP cable
Removing the eDP cable
Prerequisites
NOTE: The eDP cable removal procedure is applicable only for systems with plastic chassis.
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the wireless card.
5. Remove the display assembly.
6. Remove the hinge caps.
7. Remove the display bezel.
8. Remove the hinges.
9. Remove the display panel.
About this task
The following image indicates the location of the eDP cable and provides a visual representation of the removal procedure.
86 Removing and installing components
