Next steps
1. Install the battery.
2. Install the base cover.
3. Follow the procedure in after working inside your computer.
Display bezel
Removing display bezel
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the display assembly.
Steps
1. Remove the four (M2.5x3.5) screws that secure the display bezel to the panel.
NOTE:
The stickers covering the display bezel screws can be removed along with the screws and do not need to be
peeled off first. When removing, apply pressure with a screwdriver on top of the sticker and rotate to remove both
the sticker and the display bezel screw together.
52 Removing and Installing
