Dell P56F Service Manual

Screw list
The following table provides the list of screws that are used for securing different
components to the computer.
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Base cover Palm-rest
assembly
M2x3 T5 10
System badge Palm-rest
assembly
M2x8 2
Battery (half-
length)
Palm-rest
assembly
M2x4 4
Battery (full-
length)
Palm-rest
assembly
M2x4 7
Hard-drive
cage
Hard-drive
assembly
M2x4 4
Solid-state
drive (half-
length)
System board M2x3 1
Solid-state
drive
Solid-state
drive bracket
M2x2 1
Solid-state
drive (full-
length)
System board M2x3 1
Speakers Palm-rest
assembly
M2x2 4
Fan System board M2x4 4
12

Dell P56F Specifications

General

Model	Dell P56F
Category	Laptop
Display Size	15.6 inches
Storage	256GB SSD
Display	15.6-inch
Display Resolution	1920 x 1080
GPU	Intel HD Graphics 620
Operating System	Windows 10 Home
Battery	42Whr
Weight	2.0 kg
CPU	Intel Core i5-7200U
Graphics	Intel UHD Graphics 620
