Dell P56F Service Manual

Removing the antenna module
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
NOTE: These instructions are applicable only for laptops with a non-
touchscreen display.
1 Remove the base cover.
2 Remove the battery (half-length) or the battery (full-length).
3 Remove the wireless card.
4 Remove the display assembly.
5 Remove the antenna cover.
6 Remove the display hinges.
Procedure
1 Peel the tape that covers the antenna cables.
2 Remove the four screws (M2x4) that secure the antenna module to the display
assembly.
90

Dell P56F Specifications

General

Model	Dell P56F
Category	Laptop
Display Size	15.6 inches
Storage	256GB SSD
Display	15.6-inch
Display Resolution	1920 x 1080
GPU	Intel HD Graphics 620
Operating System	Windows 10 Home
Battery	42Whr
Weight	2.0 kg
CPU	Intel Core i5-7200U
Graphics	Intel UHD Graphics 620
