Replacing the antenna module
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the antenna module with the screw holes on the display
assembly.
2 Replace the four screws (M2x4) that secure the antenna module to the display
assembly.
3 Adhere the tape that covers the antenna cable.
Post-requisites
1 Replace the display hinges.
2 Replace the antenna cover.
3 Replace the display assembly.
4 Replace the wireless card.
5 Replace the battery (half-length) or the battery (full-length).
6 Replace the base cover.
92
