Dell P56F - Post-Requisites

2 Slide the memory module rmly into the slot at an angle and gently press the
memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and
reinstall it.
Figure 20. Replacing the memory modules
1
memory module 2 notch
3 tab 4 memory-module slot
5 securing clips
Post-requisites
1 Replace the battery (half-length) or the battery (full-length).
56
