PowerConnect 5324 Release Notes
System Firmware Version 2.0.0.39 Subject to Change Without Notice Page 17
channel-group
Update the command as follows:
Field Current Guide Change to:
User
Guidelines
There are no user guidelines for this
command.
For redundancy reasons, the LACP port channel
can accept up to 16 ports but only 8 will be active
at the same time.
wrr-queue bandwidth
Update the command as follows:
Field Current Guide Change to:
User
Guidelines
All 4 queues are participating
excluding the queues that are
assigned as expedite queues. The
weights of these queues are ignored
in the ratio calculation.
All 4 queues participate in the WRR
exclude the expedite queues, in
which case the corresponded weight
is ignored (not used in the ratio
calculation). The expedite queue is a
priority queue, and it is serviced until
empty before the other queues are
serviced.
All 4 queues are participating excluding the
queues that are assigned as Strict Priority
(SP) queues. The weights of these queues
are ignored in the ratio calculation.
All 4 queues participate in the WRR exclude
the Strict Priority (SP) queues, in which case
the corresponded weight is ignored (not
used in the ratio calculation). The expedite
queue is a priority queue, and it is serviced
until empty before the other queues are
serviced.
rmon collection history
Update the command as follows:
Field Current Guide Change to:
Syntax
Parameter
owner ownername—Records the RMON
statistics group owner name. If
unspecified, the name is an empty string.
owner ownername—Records the RMON
statistics group owner name. If unspecified, the
name is an empty string (Range: 0-20
characters).
switchport trunk allowed vlan
Update the command as follows:
Field Current Guide Change to:
Syntax
Parameter
switchport trunk allowed vlan {add
vlan-list | remove vlan-list }
add vlan-list—List of VLAN IDs to
add. Separate non consecutive VLAN
IDs with a comma and no spaces. A
hyphen designates a range of IDs.
switchport trunk allowed vlan {add vlan-list/all
| remove vlan-list/all }
add vlan-list—List of VLAN IDs to add.
Separate non consecutive VLAN IDs with a
comma and no spaces. A hyphen
designates a range of IDs. The option all
