General| Switching Capacity | 48 Gbps |
|---|---|
| VLAN Support | Yes |
| Rack Mountable | Yes |
| Device Type | Switch |
| MAC Address Table Size | 8K entries |
| RAM | 64 MB |
| Flash Memory | 8 MB |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Jumbo Frame Support | Yes |
| Ports | 24 x 10/100/1000 + 2 x SFP |
| Management | Web-based, SNMP, CLI |
| Enclosure Type | Rack-mountable |
| Routing Protocol | Static IP routing |
| Remote Management Protocol | SNMP 1, 2, 3 |
| Features | Flow control, auto-negotiation, port mirroring, Quality of Service (QoS) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Operating Temperature | 0 °C to 45 °C |
| Storage Temperature | -20 °C to 70 °C |
| Humidity | 5% to 95% (non-condensing) |
| Layer | Layer 2 |
