Table 7. Rear view of the system (continued)
Item Ports, panels, or slots Icon Description
access BIOS using the step
th
rough mode. When pressed,
the system ID LED in the back
panel blinks until either the
front or rear button is pressed
again. Press the button to
toggle between on or off
mode.
5 VGA port
Enables you to connect a
di
splay device to the system.
6 OCP NIC port (optional) N/A The OCP NIC card supports
OCP 3.0. The NIC ports are
integrated on the OCP card
which is connected to the
system board.
7 USB 2.0
Supports 4-pin, USB 2.0
co
mpliant devices
8 USB 3.0 N/A Supports 9-pin, USB 3.0
compliant devices
9 Dedicated iDRAC9 Ethernet
port
Enables you to remotely
ac
cess iDRAC. For more
information, see the
Integrated Dell Remote
Access Controller User's
Guide at www.dell.com/
poweredgemanuals.
10 NIC ports (2)
The NIC ports that are
in
tegrated on the LOM card
provide network connectivity
which is connected to the
system board.
NOTE: For more information about ports, panels, and slots, see the T
echnical specifications section.
Dell PowerEdge T560 system overview 23
