Dell PowerFlex Custom Node R6525 - Page 21

Table 9. Configuration 0 - No riser
Card type Slot priority Maximum number of cards
Broadcom (OCP: 25 Gb)
Internal Slot
1
Mellanox (OCP: 25 Gb)
Internal Slot
1
FOXCONN (Front PERC)
Internal Slot
1
FOXCONN (Front PERC, 500)
Not supported
0
Table 10. Configuration 1: R1a
Card type Slot priority Maximum number of cards
Mellanox (NIC: 100 Gb) 1 1
Mellanox (NIC: 25 Gb) 1 1
Emulex (HBA: FC32) 1 1
QLogic (HBA: FC32) 1 1
Emulex (HBA: FC16) 1 1
QLogic (HBA: FC16) 1 1
FOXCONN (HBA355E) 1 1
Dell PERC Adapter 1 1
Dell BOSS Adapter 1 1
FOXCONN (Front PERC, 500)
Not supported
0
FOXCONN (Front PERC)
Internal Slot
1
Dell Front PERC
Internal Slot
1
Broadcom (OCP: 25 Gb)
Internal Slot
1
Mellanox (OCP: 25 Gb)
Internal Slot
1
Table 11. Configuration 2: R2a + R3a
Card type Slot priority Maximum number of cards
Inventec (BOSS) 1 1
T4 GPU (Nvidia) 1, 2, 3 3
Mellanox (NIC: 100 Gb) 1, 2, 3 3
Mellanox (NIC: 50 Gb) 1, 2, 3 3
Mellanox (NIC: 25 Gb) 1, 2, 3 3
Broadcom (NIC: 25 Gb) 1, 2, 3 3
Emulex (HBA: FC32) 1, 2, 3 3
QLogic (HBA: FC32) 1, 2, 3 3
Emulex (HBA: FC16) 1, 2, 3 3
QLogic (HBA: FC16) 1, 2, 3 3
FOXCONN (HBA355E) 1, 2 , 3 2
Inventec (Front PERC)
Internal Slot
1
Component installation guidelines 21
