Table 11. Configuration 2: R2a + R3a (continued)
Card type Slot priority Maximum number of cards
Foxconn (Front PERC)
Internal Slot
1
Mellanox (OCP: 100 Gb)
Internal Slot
1
Mellanox (OCP: 50 Gb)
Internal Slot
1
Broadcom (OCP: 25 Gb)
Internal Slot
1
Mellanox (OCP: 25 Gb)
Internal Slot
1
Table 12. Configuration 2: R2a + R3a
Card type Slot priority Maximum number of cards
Dell BOSS Adapter 2, 1, 3 1
T4 GPU (Nvidia) 2, 1, 3 3
Mellanox (NIC: 100 Gb) 2, 1, 3 3
Mellanox (NIC: 25 Gb) 2, 1, 3 3
Broadcom (NIC: 25 Gb) 2, 1, 3 3
Emulex (HBA: FC32) 2, 1, 3 3
QLogic (HBA: FC32) 2, 1, 3 3
Emulex (HBA: FC16) 2, 1, 3 3
QLogic (HBA: FC16) 2, 1, 3 3
FOXCONN (HBA355E) 2, 1, 3 2
Dell PERC Adapter 2, 1, 3 3
Dell Front PERC
Internal Slot
1
Broadcom (OCP: 25 Gb)
Internal Slot
1
Mellanox (OCP: 25 Gb)
Internal Slot
1
Table 13. Configuration 3: R2b + R3a
Card type Slot priority Maximum number of cards
Mellanox (NIC: 25 Gb) 3 1
Broadcom (NIC: 25 Gb) 3 1
Emulex (HBA: FC32) 3 1
QLogic (HBA: FC32) 3 1
Emulex (HBA: FC16) 3 1
QLogic (HBA: FC16) 3 1
FOXCONN (HBA355E) 3 1
Dell PERC Adapter 3 1
Dell BOSS Adapter 3 1
Mellanox (NIC: 100 Gb) 2, 1, 3 3
Mellanox (NIC: 50 Gb) 2, 1, 3 3
